Electric Motor: | 48 V- BLDC motor with inner rotor |
Rated Output | 1 KW / 2000RPM |
Max. Power: | 2.5 KW |
Torque: | Rate:5.5Nm; Max:25Nm |
Max Motor Speed: | 4,000 RPM |
Final Drive: | 1:7.1 |
Drive Mode: | Stage 1 , Stage 2 |
Cooling System: | Air Cooled |
Powerpack: | Swappable lithium-Ion battery, L*W*H:145*91*270mm, Weight:5.9kg(13lb) |
Capacity/Energy: | 20 AH/960 Wh |
Charging Time 100%: | Standard: 4 Hours , Quick Charge: 2.5 Hours |
Charging Time 80%: | Standard: 3.2 Hours , Quick Charge: 2 Hours |
Run Time: | 2 hours in ideal conditions with full charge |
Charger Line Voltage: | 90-264 V/50-60 Hz |
Charging Input: | 1.3A@230V(AC) |
Charging Power: | 290 W |
Frame: | Aluminum twin-spar with Double-Cradle |
Handlebar: | Tapered Aluminum ϕ22mm |
Front Suspension: | Hydraulic Conventional Telescopic Fork ϕ33mm, Length 600mm(24.25inches) |
Rear Suspension: | DNM Rebound/Preload Adjustable,Length 230mm(9inches) |
Suspension Travel Front /Rear: | 100mm(3.9ins)/97mm(3.8inches) |
Front Brake: | Hydraulic caliper w/ 190 mm petal-style rotor; right-hand-lever actuated |
Rear Brake: | Hydraulic caliper w/ 190 mm petal-style rotor; left-hand-lever actuated |
Front /Rear Rims: | 12x1.6 spoke aluminum rim |
Front /Rear Tires: | 60/100-12 Kenda® Millville K771 knobby tire |
Chain: | 428H |
Steering Head Angle: | 25° |
Triple Clamp Offset: | 25° |
Trail: | 32mm |
Wheel Base: | 970mm (38inches) |
Handlebar Height: | 860mm (33.8inches) |
Ground Clearance: | 200mm (7.8inches) |
Seat Height: | Adjustable 630mm (24.8inches) / 650mm (25.5inches) |
Overall length: | 1395mm (55inches) |
Overall Width: | 690mm (27.1inches) |
Overall Height: | 920mm (36.2inches) |
Max Load: | 45kg (99lb) |
Weight: | 48kg (106lb) |
